HDT5316GJB
The detachable garbage truck is a kind of quasi-use garbage disposal equipment that uses a retractable hook arm to realize the self-loading and dumping of garbage in the garbage bin.
The detachable garbage truck is a kind of quasi-use garbage disposal equipment that uses a retractable hook arm to realize the self-loading and dumping of garbage in the garbage bin.
|
HDT5316GJB |
||
|
Whole Vehicle |
Items |
Technical Parameters |
|
Chassis Model |
ZZ1315N3063E1 |
|
|
Curb Weight（kg） |
13800 |
|
|
Full Load Weight（kg） |
31000 |
|
|
Outline Dimension(mm) (L×W×H) |
9700×2496×3800 |
|
|
Wheelbase (mm) |
1800+3050+1350 1800+3025+1400 |
|
|
Min Ground Clearance (mm) |
≥243 |
|
|
Min Turning Diameter (m) |
≤24 |
|
|
Oil Consumption/100km (L) |
≤45 |
|
|
Braking Distance（V0=30km/h） |
≤10（Full load）；≤9（No load） |
|
|
Engine |
Displacement (L) |
6.870 |
|
Rated Power/Speed（kW/rpm） |
248（2300） |
|
|
Max Torque（N.m/rpm） |
1250/1200-1800 |
|
|
Emission Standards |
China Ⅴ |
|
|
Upload Parameters |
Geometric Capacity of Mixing Drum(m3) |
14.4 |
|
Mixing Capacity(m3) |
7.82 |
|
|
Drum Inclination(°) |
12 |
|
|
Drum Rotating Speed（r/min） |
0~16 |
|
|
Feeding Speed(m3/min) |
≥3 |
|
|
Discharging Speed(m3/min) |
≥0.8 |
|
|
Concrete Residual Rate(%) |
≤3 |
|
|
Slump Range(mm) |
100-230 |
|
|
Water Tank Capacity(L) |
400 |
|
|
Configuration |
Engine |
MC07.34-50 |
|
Gearbox |
HW10 |
|
|
Steering Mechanism |
WG9725478228 |
|
|
Tyre |
11.00R20 |
|
|
Reducer |
Bonfiglioli |
|
|
Oil Pump |
Eaton |
|
|
Motor |
Eaton |
|
|
Radiator |
Made in China,with vacuum meter |
|
